Name: WPY Multifunctional Scale
SKU: E010
Availability: OutOfStock

PRODUCT SERIES

SKU	Model	Verification	Maximum capacity	Readability	Pan size
WP-111-0116	WPY 30/F1	yes	30 kg	10 g	300×300 mm
WP-111-0006	WPY 0.6/D2	yes	0,6kg	0,2g	195×195mm
WP-111-0126	WPY 1.5/F1	yes	1,5kg	0,5g	300×300mm
WP-111-0007	WPY 1.5/D2	yes	1,5kg	0,5g	195×195mm
WP-111-0008	WPY 3/D2	yes	3kg	1g	195×195mm
WP-111-0003	WPY 6/D2	yes	6kg	2g	195×195mm
WP-111-0123	WPY 15/D2	yes	15kg	5g	195×195mm
WP-111-0113	WPY 3/F1	yes	3kg	1g	300×300mm
WP-111-0114	WPY 6/F1	yes	6kg	2g	300×300mm
WP-111-0115	WPY 15/F1	yes	15kg	5g	300×300mm
WP-111-0128	WPY 15/C2	yes	15kg	5g	400×500mm
WP-111-0117	WPY 30/C2	yes	30kg	10g	400×500mm
WP-111-0118	WPY 60/C2	yes	60kg	20g	400×500mm
WP-111-0119	WPY 150/C2	yes	150kg	50g	400×500mm
WP-111-0071	WPY 300/C2	yes	300kg	100g	400×500mm
WP-111-0130	WPY 15/C3	yes	15kg	5g	500×700mm
WP-111-0131	WPY 30/C3	yes	30kg	10g	500×700mm
WP-111-0133	WPY 60/C3	yes	60kg	20g	500×700mm
WP-111-0121	WPY 150/C3	yes	150kg	50g	500×700mm
WP-111-0122	WPY 300/C3	yes	300kg	100g	500×700mm

Please, use model selector above to see product description.

Please, use model selector above to see product datasheet.

Maximum capacity [Max]	0,6kg
Minimum load	4g
Readability [d]	0,2g
Tare range	-0,6kg
Stabilization time	2s
Operating temperature	-10 ÷ +40°C
Weighing pan dimensions	195×195mm
Power supply	100 ÷ 240 V AC 50 ÷ 60 Hz / 12 V DC
Display	5,7'' (panel touchscreen)
Communication interface	2×USB, 2×RS 232, Ethernet, 4Inputs/4Outputs (digital), Wireless Connection
Packaging dimensions	490×300×150mm
Adjustment	external
Net weight
Gross weight
Atmospheric humidity
Power consumption
Add weighing platform module
Construction
Controling device dimensions
Housing
Inputs/Outputs (option)
Net weight/gross weight	2,7 / 3,6kg
OIML Class	III
Operation time on batteries
Protection class	IP 43
Verification scale interval
Weighing pan material

Maximum capacity [Max]	1,5kg
Minimum load	10g
Readability [d]	0,5g
Tare range	-1,5kg
Stabilization time	2s
Operating temperature	-10 ÷ +40°C
Weighing pan dimensions	195×195mm
Power supply	100 ÷ 240 V AC 50 ÷ 60 Hz / 12 V DC
Display	5,7'' (panel touchscreen)
Communication interface	2×USB, 2×RS 232, Ethernet, 4Inputs/4Outputs (digital), Wireless Connection
Packaging dimensions	490×300×150mm
Adjustment	external
Net weight
Gross weight
Atmospheric humidity
Power consumption
Add weighing platform module
Construction
Controling device dimensions
Housing
Inputs/Outputs (option)
Net weight/gross weight	2,7 / 3,6kg
OIML Class	III
Operation time on batteries
Protection class	IP 43
Verification scale interval
Weighing pan material

Maximum capacity [Max]	3kg
Minimum load	20g
Readability [d]	1g
Tare range	-3kg
Stabilization time	2s
Operating temperature	-10 ÷ +40°C
Weighing pan dimensions	195×195mm
Power supply	100 ÷ 240 V AC 50 ÷ 60 Hz / 12 V DC
Display	5,7'' (panel touchscreen)
Communication interface	2×USB, 2×RS 232, Ethernet, 4Inputs/4Outputs (digital), Wireless Connection
Packaging dimensions	490×300×150mm
Adjustment	external
Net weight
Gross weight
Atmospheric humidity
Power consumption
Add weighing platform module
Construction
Controling device dimensions
Housing
Inputs/Outputs (option)
Net weight/gross weight	2,7 / 3,6kg
OIML Class	III
Operation time on batteries
Protection class	IP 43
Verification scale interval
Weighing pan material

Maximum capacity [Max]	6kg
Minimum load	40g
Readability [d]	2g
Tare range	-6kg
Stabilization time	2s
Operating temperature	-10 ÷ +40°C
Weighing pan dimensions	195×195mm
Power supply	100 ÷ 240 V AC 50 ÷ 60 Hz / 12 V DC
Display	5,7'' (panel touchscreen)
Communication interface	2×USB, 2×RS 232, Ethernet, 4Inputs/4Outputs (digital), Wireless Connection
Packaging dimensions	490×300×150mm
Adjustment	external
Net weight
Gross weight
Atmospheric humidity
Power consumption
Add weighing platform module
Construction
Controling device dimensions
Housing
Inputs/Outputs (option)
Net weight/gross weight	2,7 / 3,6kg
OIML Class	III
Operation time on batteries
Protection class	IP 43
Verification scale interval
Weighing pan material

Maximum capacity [Max]	15kg
Minimum load	100g
Readability [d]	5g
Tare range	-15kg
Stabilization time	2s
Operating temperature	-10 ÷ +40°C
Weighing pan dimensions	195×195mm
Power supply	100 ÷ 240 V AC 50 ÷ 60 Hz / 12 V DC
Display	5,7'' (panel touchscreen)
Communication interface	2×USB, 2×RS 232, Ethernet, 4Inputs/4Outputs (digital), Wireless Connection
Packaging dimensions	490×300×150mm
Adjustment	external
Net weight
Gross weight
Atmospheric humidity
Power consumption
Add weighing platform module
Construction
Controling device dimensions
Housing
Inputs/Outputs (option)
Net weight/gross weight
OIML Class
Operation time on batteries
Protection class
Verification scale interval
Weighing pan material

WPY Multifunctional Scale
